Serveur série RS485 vers RJ45 2 canaux 2 ports Ethernet - 2-CH RS485 TO ETH (B Modbus gateway support, suitable for Modbus networking upgrade, can be used with specific configuration software. Module Communication Isolé Rail DIN Convertisseur RS485 Vers Ethernet 2 Canaux Waveshare - POE Isolé Rail Convertisseur Industriel Isolé Rail DIN Parameter Model -- 2-CH RS485 TO ETH (B) Product Type -- Serial server, Modbus Gateway, MQTT Gateway Basic Function -- Bi-directional transparent data transmission between RS485 and Ethernet Communication Interface -- RS485 port × 2, Ethernet port × 2 Power Supply -- DC 5., 5 power port, 6 ~ 45V DC screw terminal Isolation protection -- Power isolation, Signal isolation Communication Interface -- Ethernet: RJ45, 10 / 100M auto-negotiation RJ45 connector, 2 KV surge protection -- Serial port: Isolated RS485 (the 2 channels can receive and transmit independently at the same time) Serial specification --Baudrate: 300 ~ 115200 bps --Parity bit: none, odd, even, mark, space --Data bit: 5 ~ 9 bits --Flow control: N/A Software --Protocol: ETHERNET, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS --Configuration: host, web browser, device management functions library --Communication method: TCP/IP direct communication, VCOM --Operating mode: TCP server, TCP client (coexisting with TCP server), UDP, UDP multicast Environment requirement --Operating temperature: -40℃ ~ 85℃ --Humidity range: 5% ~ 95% relative humidity --Dimensions: L × W × H: 78., 0 × 72., 5 × 24., 2 mm Package Content 2-CH RS485 TO ETH (B) x1 Development Resources https://www., waveshare. MQTT/JSON to Modbus, more flexible conversion between different protocols Multiple protection, safe and stable, onboard power supply and signal isolation, built-in TVS and resettable fuse and protection diode etc. Serveur série Ethernet RS232 RS485 à RJ45 2 ports Ethernet - RS232 RS485 TO ETH (B Serveur Série Industriel, Serveur Série RS485 vers WiFi, Convertisseur De Périphérique Ethernet Support Ethernet Port Cascade, onboard 2-ch Ethernet Ports for communication and cascade, either one can be used for dual serial server network communication, while the other one can be used for cascading or communication with other devices Supports TCP server / TCP client / UDP multicast / UDP mode. com/wiki/RS232/485/422_TO_POE_ETH_(B)
